HDLE-15 Hydraulic Driven Booster

HDLE 15 Hydraulic Driven Booster

RFQ Icon
Technical Data
Maximum Hydraulic Drive Pressure pH: 210 bar / 3,045 psi
Maximum Hydraulic Flow Rate: 30 l/min
Pressure Ratio i: 1:2
Minimum Gas Inlet Pressure pA min.: 7 bar / 101 psi
Maximum Gas Inlet Pressure pA max.: 300 bar / 4,350 psi
Maximum Gas Outlet Pressure pB: 300 bar / 4,350 psi
Displacement Volume: 244 cm³
Maximum Cycles: 60 / min
Stroke Length: 97 mm
Hydraulic Drive: 1/4" NPT
Gas Inlet: 1/4" NPT
Gas Outlet: 1/4" NPT
Max. Operating Temperature: 60°C
Weight: 22 kg
Height: 208 mm
Length: 622 mm
Width: 145 mm

For Complete Product Information Visit or Download PDF. HDLE-15 Hydraulic Driven BoosterPDF Icon
