Line Filters - Dual Disc Line Filters

Pressures to 21,000 psi

MAXIMATOR dual-disc line filters are used to filter process fluids in high pressure systems. This design helps remove the large particles first through a coarse primary disc, which then allows a secondary disc to provide a smaller micron filtration. These filter elements are designed to withstand pressure surges without cracking, flaking, or rupturing. Filter elements come standard in the following micron sizes: 5/8, 8/30, 30/56 (secondary/primary). Filters are rated for temperatures -60ºF to 660ºF. All line filters come with glands and collars.

Materials for Dual Disc Line Filters

Body: cover, cover gland: 316 series stainless steel

Element: 300 series stainless steel

Catalog
Number

Pressure
Rating (psi)

Orifice (in.)

Micron Size

Connection Type

Filter Element
Area (in.2)

Dimensions (in.)
A
B
C
(Hex.)
21DF9M - 5/8
21,000
0.312
5/8
9MF
0.25
2.68
4.96
1.44
21DF9M - 8/30
8/30
21DF9M - 30/56
30/56



It is recommended that all fluids entering a high pressure system be thoroughly cleaned. Maximator filters are designed to remove small amounts of process particles. Pressure differential should not exceed 1000 psi across the filter elements.

All dimensions are for reference only and subject to change.

All general terms and conditions of sale, including limitations of our liability, apply to all products and services sold.
