Double Air Head - Two Stage Gas Boosters

Double Air Head - Two Stage Gas Boosters

RFQ Icon

For the greatest combination of pressure and compression ratios the double acting– two stage – double air head models are ideal. There are four double air head – two stage boosters, DLE5-30-2 Gas Booster, DLE15-30-2 Gas Booster, DLE15-75-2 Gas Booster and DLE30-75-2 Gas Booster. These boosters provide maximum flow in low air drive and gas supply pressure conditions.

For high pressure applications or where air drive pressure is low High Pressure Technologies offers three double acting – single stage boosters with a double air head. These models include the DLE15-2 Gas Booster, DLE30-2 Gas Booster and DLE75-2 Gas Booster.

Styles

Model

Ratio

Supply Pressure

Outlet

Pressure

Stall

Pressure

Max

Cycle

Displacement

Per Cycle

Minimum

Maximum





Double Acting,

Two Stage,

Double Air Head

DLE2-5-2

10:1

0 psi

1.6 x Pa

1,450 psi

10Pa + 2.5Ps

90

56.2 cu in

DLE5-15-2

30:1

30 psi

3.2 x Pa

4,350 psi

30Pa + 3Ps

100

22.7 cu in

DLE5-30-2

60:1

30 psi

1.0 x Pa

8,700 psi

60Pa + 6Ps

100

22.7 cu in

DLE15-30-2

60:1

100 psi

15.0 x Pa

8,700 psi

60Pa + 2Ps

100

7.4 cu in

DLE15-75-2

150:1

100 psi

5.0 x Pa

21,750 psi

150Pa +5Ps

100

7.4 cu in

DLE30-75-2

150:1

220 psi

24.0 x Pa

21,750 psi

150Pa + 2.5Ps

110

3.6 cu in

DLE30-75-2-25

150:1

220 psi

24.0 x Pa

25,000 psi

150Pa + 2.5Ps

110

3.6 cu in

DLE30-75-2-30

150:1

220 psi

40.0 x Pa

30,000 psi

150Pa + 2.5Ps

100

3.6 cu in
