AS-MPLV2-10GH Air Pressure Amplifier System

Maximator® AS-MPLV2-10GH Air Amplifier Systems are ideal for turn-key installation at work stations or machine centers to boost plant air pressure for tools or operation of pneumatic clamps, cylinders and other equipment. These systems provide short-term high flow air or constant flow with reserve, at a constant regulated output pressure. Storage tank is per A.S.M.E. Code and CRN (Canada) and comes with a safety relief valve, drain valve and pressure gauge.

Each 200 psi and 250 psi system is also equipped with an inlet air filter and outlet pressure regulator with gauge, all mounted on a common base. The 500 psi and 600 psi systems are equipped with an inlet air filter and inlet air pressure regulator with gauge. High pressure outlet regulator with gauge is available as an option (Add "-R" for a 1/4" FNPT regulator or "-1/2 R" for a 1/2" FNPT high flow regulator to system catalog number). Maximator® Air Amplifier Systems are available in a number of arrangements and custom designed units are also available to suit your specific flow and pressure requirements. Please consult factory.

AS-MPLV2-10GH Air Amplifier Systems

This email address is being protected from spambots. You need JavaScript enabled to view it.RFQ Icon

Technical Specification

2:1 Ratio Systems
Air Amplifier Type
Pressure Ratio
Tank Size
10 gal
Min. Supply Pressure
15 psi
Max. Supply Pressure
150 psi
Max. Related Pressure
200 psi
Stall Pressure
Pa + Ps
Max. Temperature
180 ºF
Stroke Capacity(inˆ3)
Inlet Connection
1/2" FNPT
Outlet Connection
1/2" FNPT
Overall Size (L x W x H)
36 x 14 x 18 in
18.00 in
63 lb
Mounting Dimensions
9.25 x 18.00 x 0.44 in


AS-MPLV2-10GH Diagram


MPLV2 FlowChart
