AS-GPLV2-15GH Air Pressure Amplifier System

Maximator® AS-GPLV2-15G Air Amplifier AS-GPLV2-15GH Air Pressure Amplifier SystemsSystems are ideal for turn-key installation at work stations or machine centers to boost plant air pressure for tools or operation of pneumatic clamps, cylinders and other equipment. These systems provide short-term high flow air or constant flow with reserve, at a constant regulated output pressure. Storage tank is per A.S.M.E. Code and CRN (Canada) and comes with a safety relief valve, drain valve and pressure gauge.

Each 200 psi and 250 psi system is also equipped with an inlet air filter and outlet pressure regulator with gauge, all mounted on a common base. The 500 psi and 600 psi systems are equipped with an inlet air filter and inlet air pressure regulator with gauge. High pressure outlet regulator with gauge is available as an option (Add "-R" for a 1/4" FNPT regulator or "-1/2 R" for a 1/2" FNPT high flow regulator to system catalog number). Maximator® Air Amplifier Systems are available in a number of arrangements and custom designed units are also available to suit your specific flow and pressure requirements. Please consult factory.

This email address is being protected from spambots. You need JavaScript enabled to view it.RFQ Icon
2:1 Ratio Systems
Air Amplifier Type
Tank Size
15 gal
System Rating
200 psi
Inlet Connection
1/2" FNPT
Outlet Connection
1/2" FNPT
Stroke Capacity(inˆ3) 116
Overall Size (L x W x H)
39 x 15 x 26 in
113 lb
Mounting Dimensions
11.00 x 20.00 x 0.44in
Option Available
Air Control Unit (ACP)
Valves and fittings


AS-GPLV2-15GH Diagram


GPLV2 Flowchart
