AS-MPLV2-1G Air Amplifier System

Maximator® AS-MPLV2-1G Air PressureAS-MPLV2-1G Air Amplifier System Amplifiers are designed to boost plant air pressure or increase the supply air pressure at work stations and pneumatically operated machinery when the available working pressure is insufficient. Air operated tools become more efficient when coupled with air amplifiers. These amplifiers are capable of generating pressures from 30 psi to 4,350 psi.

This email address is being protected from spambots. You need JavaScript enabled to view it.RFQ Icon
Type
2:1 Ratio Systems
Air Amplifier Type
Pressure Ratio
2:1
Tank Size
1.6 gal
Min. Supply Pressure
15 psi
Max. Supply Pressure
150 psi
Max. Related Pressure
250 psi
Stall Pressure
Pa + Ps
Max. Temperature
180 ºF
Stroke Capacity(inˆ3)
16.72
Inlet Connection
1/2" FNPT
Outlet Connection
1/2" FNPT
Overall Size (L x W x H)
13 x 8 x 22 in
Length
13.00 in
Width
8.00 in
Height
22.00 in
Weight
60 lb
Mounting Dimensions
7.13 x 9.00 x 0.38 in



AS-MPLV2-1G Diagram

MPLV2 FlowChart

 MPLV2
