Air Driven Gas Boosters - Increasing Pressure From 30 PSI to 36,000 PSI


Single Stage Gas Boosters  Two Stage Gas Boosters  Double Acting Gas Boosters

Maximator's Air Driven Gas Booster series is suitable for the oil free compression of gases and air. Industrial gases such as Argon, Air, Carbon Dioxide, Helium, Hydrogen, Natural Gas, Nitrogen, and Xenon can be compressed to operating pressures of 36,000 psi and Oxygen to 5,000 psi. In addition to the range of Gas Boosters available for industrial applications, we specialize in Oxygen Gas Boosters and Oxygen Rebreather Gas Boosters for both the Recreational Scuba and the Commercial diving industry.

Gas Booster Features:

  • Pressures to 36,000 psi for most gases and 5,000 psi for oxygen
  • Easy to install and operate
  • Compact, lightweight design
  • Single or double acting and two stage models
  • Double air head available in single and two stage boosters
  • No electrical power required
  • Requires no lubrication
  • Boosters are contaminant free
  • Units can be operated in series or parallel
  • Variety of pressure and compression ratios available

Gas Booster Applications:

  • Low pressure gas reclaim from storage bottles
  • Oxygen boosting
  • Gas pressure and leak testing
  • Charging of accumulators
  • Boosting gas pressures from nitrogen or Oxygen generators
  • Nitrogen injection for molding machines
  • Breathing air systems for scuba and fire department tanks
  • Leak detection systems
  • Low pressure autoclaves
  • Typical Gases include air, nitrogen, helium, oxygen, carbon dioxide, nitrous oxide, neon, argon, hydrogen, carbon monoxide, methane, ethylene and natural gas. For any other gas please contact us for compatibility.

Styles

Model



Ratio



Supply Pressure

Outlet

Pressure

Stall

Pressure

Max

Cycle

Displacement

Per Cycle

Minimum

Maximum



Single Acting,

Single Stage

DLE2-1

2:1

0 psi

290 psi

290 psi

2Pa

100

56.2 cu in

DLE5-1

5:1

30 psi

725 psi

725 psi

5Pa

110

22.7 cu in

DLE15-1

15:1

100 psi

2,175 psi

2,175 psi

15Pa

130

7.4 cu in

DLE30-1

30:1

220 psi

4,350 psi

4,350 psi

30Pa

130

3.6 cu in

DLE75-1

75:1

500 psi

10,875 psi

10,875 psi

75Pa

130

1.5 cu in





Double Acting,

Single Stage









DLE2

2:1

0 psi

580 psi

580 psi

2Pa + Ps

90

112.5 cu in

DLE5

5:1

30 psi

1,450 psi

1,450 psi

5Pa + Ps

110

45.5 cu in

DLE15

15:1

100 psi

4,350 psi

4,350 psi

15Pa + Ps

120

14.8 cu in

DLE30

30:1

220 psi

8,700 psi

8,700 psi

30Pa + Ps

120

7.3 cu in

DLE75

75:1

500 psi

21,750 psi

21,750 psi

75Pa + Ps

120

3.0 cu in





Double Acting,

Single Stage,

Double Air Head









DLE2-2

4:1

0 psi

60 psi

580 psi

4 Pa + Ps

90

112.5 cu in

DLE5-2

10:1

60 psi

1,450 psi

1,450 psi

10Pa + Ps

100

45.5 cu in

DLE15-2

30:1

145 psi

4,350 psi

4,350 psi

30Pa + Ps

100

14.8 cu in

DLE30-2

60:1

290 psi

8,700 psi

8,700 psi

60Pa + Ps

100

7.3 cu in

DLE75-2

150:1

650 psi

21,750 psi

21,750 psi

150Pa + Ps

100

3.0 cu in

DLE75-2-2100

150:1

660 psi

30,000 psi

30,000 psi

150Pa + Ps

100

3.0 cu in

High Flow

Double Acting,

Single Stage,

Double Air Head

8DLE3

3.3:1

0 psi

580 psi

580 psi

3.3Pa + Ps

80

250 cu in

8DLE6

6.6:1

0 psi

580 psi

580 psi

6.6 Pa + Ps

80

125 cu in





Double Acting,

Two Stage











DLE2-5

5:1

0 psi

0.8 x Pa

1,450 psi

5Pa + 2.5Ps

100

56.2 cu in

DLE5-15

15:1

30 psi

1.6 x Pa

4,350 psi

15Pa + 3Ps

110

22.7 cu in

DLE5-30

30:1

30 psi

0.5 x Pa

8,700 psi

30Pa + 6PS

110

22.7 cu in

DLE15-30

30:1

100 psi

7.5 x Pa

8,700 psi

30Pa +2Ps

120

7.4 cu in

DLE15-75

75:1

100 psi

2.5 x Pa

12,325 psi

75Pa + 5Ps

120

7.4 cu in

DLE30-75

75:1

220 psi

12.0 x Pa

15,225 psi

75Pa + 2.5Ps

120

3.6 cu in





Double Acting,

Two Stage,

Double Air Head











DLE2-5-2

10:1

0 psi

1.6 x Pa

1,450 psi

10Pa + 2.5Ps

90

56.2 cu in

DLE5-15-2

30:1

30 psi

3.2 x Pa

4,350 psi

30Pa + 3Ps

100

22.7 cu in

DLE5-30-2

60:1

30 psi

1.0 x Pa

8,700 psi

60Pa + 6Ps

100

22.7 cu in

DLE15-30-2

60:1

100 psi

15.0 x Pa

8,700 psi

60Pa + 2Ps

100

7.4 cu in

DLE15-75-2

150:1

100 psi

5.0 x Pa

21,750 psi

150Pa +5Ps

100

7.4 cu in

DLE30-75-2

150:1

220 psi

24.0 x Pa

21,750 psi

150Pa + 2.5Ps

110

3.6 cu in

DLE30-75-2-25

150:1

220 psi

24.0 x Pa

25,000 psi

150Pa + 2.5Ps

110

3.6 cu in

DLE30-75-2-30

150:1

220 psi

40.0 x Pa

30,000 psi

150Pa + 2.5Ps

100

3.6 cu in

Double Acting,

Two Stage,

Triple Air Head

DLE30-75-3-36

225:1

440 psi

30.0 x Pa

36,000 psi

225Pa + 2.5Ps

100

3.6 cu in

Gas Boosters Product Lines:

Single Acting - Single Stage Gas Booster
dle75-1

  • High Pressure Technologies offers five gas boosters in the single acting - single stage configuration.These gas booster pump models include the DLE2-1 Gas Booster, DLE5-1 Gas Booster, DLE15-1 Gas Booster, DLE30-1 Gas Booster and DLE75-1 Gas Booster. Single stage – single acting gas boosters are the smallest and lightest of the Maximator family, yet capable of output pressures up to 10,000 psi.



Double Acting - Single Stage Gas Boosters
dle booster 5vk6

  • High Pressure Technologies offers Double acting – single stage gas booster pumps which provide twice the flow rate of a single acting gas boosters at a more constant output. Double acting - single stage gas booster models include DLE2 Gas Booster, DLE5 Gas Booster, DLE15 Gas Booster, DLE30 Gas Booster and DLE75 Gas Booster.

Two Stage Gas Boosters
dle booster 5vk6

  • High Pressure Technologies offers six models of gas boosters in single air head, double acting – two stage configuration.These gas boosters include the DLE2-5 Gas Booster, DLE5-15 Gas Booster, DLE5-30 Gas Booster, DLE15-30 Gas Booster, DLE15-75 Gas Booster, and DLE30-75 Gas Booster. These gas boosters are ideal for low gas supply pressures such as salvaging bottled gas or boosting pressures from a nitrogen generator or vaporizer

Double Air Head - Single Stage Gas Booster
dle30-2

  • For the greatest combination of pressure and compression ratios the double acting– two stage – double air head gas booster models are ideal. There are several models of the double air head – two stage gas booster pump, DLE2-5-2, DLE5-15-2, DLE5-30-2, DLE15-30-2, DLE15-75-2, DLE30-75-2, DLE30-75-2-25 and DLE30-75-2-30 Gas Boosters. These gas boosters provide maximum flow in low air drive and gas supply pressure conditions.

Double Air Head -Two Stage Gas Booster
dle30-2

  • For the greatest combination of pressure and compression ratios the double acting– two stage – double air head gas booster pump models are ideal. There are four double air head – two stage gas boosters, the DLE5-30-2 Gas Booster, DLE15-30-2 Gas Booster, DLE15-75-2 Gas Booster and DLE30-75-2 Gas Booster. This range of gas boosters provide maximum flow in low air drive and gas supply pressure conditions.

    For high pressure gas booster applications or where air drive pressure is low High Pressure Technologies offers 5 double acting – two stage gas boosters with a double air head. These models include the DLE5-30-2 Gas Booster, DLE15-30-2 Gas Booster, DLE30-75-2 Gas Booster and the DLE30-75-2-30 Gas Booster.

Double Air Head -Two Stage Gas Booster
dle30-2

  • For the greatest combination of pressure and compression ratios the double acting– two stage – double air head gas booster models are ideal. There are four double air head – two stage gas boosters, the DLE5-30-2 Gas Booster, DLE15-30-2 Gas Booster, DLE15-75-2 Gas Booster and DLE30-75-2 Gas Booster. This range of gas boosters provide maximum flow in low air drive and gas supply pressure conditions.

    For high pressure gas booster pump applications or where air drive pressure is low High Pressure Technologies offers 5 double acting – two stage gas boosters with a double air head. These models include the DLE5-30-2 Gas Booster, DLE15-30-2 Gas Booster, DLE30-75-2 Gas Booster and the DLE30-75-2-30 Gas Booster.

Triple Air Head - Two Stage - Double Acting Gas Booster
c6951d9fda0aae0c01d4d00aad86a347 a09k

  • For the greatest combination of pressure and compression ratios the double acting– two stage – triple air head gas booster models are ideal. The DLE30-75-3-36 Gas booster is currently the only gas booster pump capable of pressures as high as 36,000 psi. This range of gas boosters provide maximum flow in low air drive and gas supply pressure conditions.

    For high pressure gas booster applications or where air drive pressure is low, High Pressure Technologies offers one double acting – single stage gas boosters with a triple air head. This model is the DLE30-75-3-36 Gas Booster.

HPT-MTIG15-30-75-2

  • High Pressure Technologies gas booster systems provide a compact, portable source for increasing gas pressures. These air driven gas booster systems are shipped assembled and fully tested, ready for turn-key installation. As with standard boosters, the gas booster systems require no electrical power, providing safe and economical operation.

    Gas booster systems are capable of compressing most gases including nitrogen, argon, helium and hydrogen up to 20,000 psi. Systems featuring special seals and cleaning can pressurize oxygen to 5,000 psi. All High Pressure Technologies gas booster systems that are for use with hazardous gases are modified to ensure vent ports are piped to a common vent connection.

mtnb4-dle75-1

  • Small, lightweight and economical, High Pressure Technologies oxygen gas booster packages are ideal for aircraft and bottle filling applications. Requires only an air source for power (70 psi minimum) and an oxygen supply bottle that can be used to as low as 100 psi.These gas booster packages will achieve 1,800 psi or 2,000 psi outlet pressures. Single and double acting gas boosters are available to meet flow rate requirements

24239353c676dc463978551025bea09e k7la

  • High Pressure Technologies nitrogen gas booster packages offer an economical method of boosting nitrogen (or other select gases or air). The gas booster package features a compact and lightweight arrangement that is turn-key and fully tested. No electrical power required for the gas booster, only a 75 psi shop air source is needed. Single and double acting gas boosters are available to meet flow rate requirements.
