Coning & Threading MachineThe Coning and Threading Machine is mounted on an industrial duty mobile cart which offers convenient and generous tool storage and a large chip collection/cutting oil system.
- Requires less operator training.
- Overall operation time is faster than other competitive machines.
- Selector knob allows the operator to “dial in” the tubing size to be coned and threaded. This automatically sets the correct thread length for faster set up.
- Coning blades are easily installed and manufactured from high quality tool steel and hardened for long service life.
- Both coning and threading are done in sequential operations controlled by the single lever with hand wheel assist. No need to remove the tube for each operation once tightened into the collet.
- Capable of 4” straight length coning and threading operation 3/8” OD thru 1” medium and high pressure tubing.
- Die head resets automatically after threading during the full retract stroke.
- Safe operation - fully enclosed cabinet eliminates pinch points and the Plexiglas cover protects the operator from cutting oil and metal chips.
- Cutting oil is filtered and returned to reservoir.
- Removable chip drum for easy cleanup, with locking lid for secure no mess shipping.
- Overall Dimensions 31” W x 19” D x 44” H. Weight: 645 lbs.
| New Coning and Threading Tool Kit |
|
Introducing a new product tool kit for the Coning and Threading of medium and high pressure tubing. All items are conveniently packaged in a sturdy tool box. Three versions of the tool kit are available. One to prepare tubing ends for Medium Pressure, one for High Pressure and one that contains items to repair both. Manual coning and threading tools are designed to thread up to 9/16” OD tubing. One size coning and threading tool with interchangeable bushings and thread dies eliminates the need for multiple tool inventories. Internal needle bearings and high strength materials offer ease of operation and extended tool life. The coning blades are designed to cut both the angle and straight areas of the tube to insure good concentricity between the sealing surfaces. We offer a complete line of high pressure valves, fittings and tubing as well as a complete line of air driven pumps, air amplifiers and gas boosters. For more information, dowload our brochure from our Catalog section. This compact, lightweight and easily transportable system incorporating an air driven gas booster hooks on to a gas bottle (not included) to boost gas to a maximum of 4,350 psig. One source drives and feeds the booster system. The booster will accept inlet pressures up to 3,000 psi. Included with the system is an adjustable 1,450-4,350 psig automatic shut-off, CGA connection and hose. It is priced competitively at $4,577.00 and is available for fast shipment. The unit is engineered to provide compact and portable high pressure gas solutions to a wide variety of end users. Industries such as the Airline Ground Support in charging both Nitrogen and Oxygen cylinders for a variety of airline applications, the oil and gas market or general industry for charging accumulators. The heavy equipment maintenance sector can utilize this system for tire and shock filling. High Pressure Technologies is a North American distributor of Maximator high pressure valves, fittings and tubing as well as power products including liquid pumps, gas boosters and air amplifiers. |
|
Introducing a new gas bottle gas booster mounted charging system suitable for industrial gas charging applications (nitrogen, inert gases or oxygen). Catalogs :: Applications :: Service & Repairs :: What's New :: Request for Quotation :: Contact Us :: XML :: Site Map
