High Pressure Pumps
Maximator high efficiency pumps are ideal for a broad variety of oil, water and chemical applications. They feature a large air piston joined to a smaller diameter plunger. The pressure ratio is the difference of these two areas and is the method of determining maximum output pressure. Higher pressures are obtained by using higher pressure ratios. Maximator model numbers reflect the pump’s nominal pressure ratios, while the technical data indicates exact ratios.

Maximator hydraulic pumps cycle automatically. The pump stops automatically when the output pressure forces and the air drive forces are equal. The pump restarts with a slight drop in the outlet pressure or an increase in the air drive pressure.

Pump performance can be affected by a number of conditions, such as freezing of mufflers or pilot valves (which is caused by moisture in air lines), inadequate inlet air line sizes and dirty filters.

Please consult High Pressure Technologies for exact flow conditions not shown in charts. High Pressure Technologies offers complete technical and service support for all Maximator pumps.


Features

  • Easy to install and operate
  • Standard ratios available for pressures to 60,000 psi
  • Economical source for hydraulic power
  • Pressure maintained without energy consumption
  • Pilot air valve is unregulated for easy restart and better pressure control range on S-D, LO and L series pumps
  • Requires no lubrication
  • Explosion proof...no electrical power required
  • External spool valve for faster and easier maintenance, standard on all but PPO series
  • Outlet pressure can be preset by use of simple optional air regulator

Models/Options

  • Stainless steel construction on most PP and all L and GX series pumps
  • Distance piece pumps available in PPSF, LSF and GX series
  • Double acting styles available on PPO, S, PP and L pumps
  • Multiple air heads available on PP and L pumps
  • Accessories available for all pumps

CAUTION: While testing has shown O-rings to provide satisfactory service life, both cyclic and shelf life may vary widely with differing service conditions, properties of reactants, pressure and temperature, and age of O-ring.

Frequent Inspection Should Be Made to detect any deterioration, and O-rings replaced as required.

How To Select a Maximator Pump

  1. Decide on the type of fluid to be pumped.
  2. Determine the available minimum plant air pressure.
  3. Finalize the required outlet pressure.
  4. Determine the required flow rate. This can be done in a number of ways:

-Is the item to be pressurized pre-filled?

-What is flow rate required at no load for filling?

-What is flow rate required at pressure?

-What is volume of item to be pressurized?

-What is the time available to fill?

-What is the time to pressurize?

Flow rates for each pump, at various air drive pressures and outlet pressures, are provided on each pump page. These pumps run very rapidly at no load and slow down as pressure increases. The pump will eventually come to a stop at the “stall” pressure, which is the air drive pressure times the pressure ratio of the pump. At this “stall” point there is no flow and no air consumption. The pump will hold the outlet pressure indefinitely and will only stroke if the outlet pressure drops or the air drive pressure is increased.

How a Liquid Pump Works

Product Lines

Oil or Oil/Water Service

SERIES PPO, S, S-D and LO

The rugged construction, light weight and wide range of pressure ratios make these series of pumps ideal for powering a variety of oil/hydraulic operations. Pressures to 14,500 psi.

> Display This Product Line

 Styles / PPO Series / S Series / S-D Series / LO Series

PPO Series Pump

Water or Oil Service

SERIES PP, L and HAND LEVER PUMPS

The PP and L series pumps are available in single or double acting models with single or double air drive heads and stainless steel materials, making them an excellent choice for water applications.

PP series pumps are available with a hand lever option.

PP pump pressures to 58,000 psi.

L pump pressures to 60,000 psi.

Hand lever pressures to 31,900 psi.

SERIES GX

This is the largest of our liquid pumps. It provides high flow of most any fluid and is built of corrosion resistant materials, inside and outside.

> Display This Product Line

 Styles / PP Series / PP-HL Series / L Series/ GX Series

PP Series Pump

Chemical Service

SERIES PPSF and LSF

PPSF and LSF series pumps are similar to the PP and L series described above and feature a distance piece and PTFE seals to address the specific requirements of chemical service.

PPSF pump pressures to 14,500 psi.

LSF pump pressures to 23,200 psi.

GX pump pressures to 14,500 psi.

DC pump pressures to 2,900 psi.

SERIES DC

The DC series pumps are dual component liquid pumps capable of pumping two different liquids, separate and at the same time, in a corrosion resistant environment.

> Display This Product Line

 Styles / PPSF Series / LSF Series / DC Series

PPSF Series Pump

Accessories

To help you complete the installation of your Maximator liquid pump, High Pressure Technologies offers a wide variety of accessories. These ancillary products are available as packaged modules or as individual components. Please consult High Pressure Technologies for details and other support services.

> Display This Product Line

 Styles / Air Control Package/ Pneumatic Pilot Switches/Lubricant/ Reservoirs / Relief Valves / Cycle Counters/ Plumbing

Air Control Package

Standard Systems

High Pressure Technologies offers complete packaged, turn-key systems for a variety of fluid and pressure applications.

High Pressure Technologies systems can be supplied for oil or water service and outlet pressures from 30 psi to 60,000 psi. To operate the power packs or portable test carts, only one shop air connection is required.

If a reservoir is included in the system, no other utility is required. High Pressure Technologies systems are designed around a basic core package, letting you choose the optional equipment you want to complete the system, making it ideal for your application.

> Display This Product Line

 Styles / Power Packs and Pump Skids /Portable Test Carts/ Test Benches

Power Packs and Pump Skids
