High Pressure Valves - Pressures to 60,000 psi


Actual Test Pressures to 65,000 psi
MAXIMATOR high pressure valves with metal to metal seats have a high level of safety and reliability under adverse operating conditions. These valves may be used both with gases and liquids. Styles /2-Way Straight /2-Way Angle /3-Way - 2 on Pressure /3-Way - 1 on Pressure /3-Way - 2-Stem Manifold /2-Way Angle - Replaceable Seat

Traceability is ensured through extensively documented data (batch number, max. pressure, material number, type designation). All high pressure valves include glands and collars.

Ordering Information

Typical catalog number: 65V4H071

65V

OPTIONS

Valve Series	O.D. Tube Size	Stem Type	Body Pattern	Extreme temperature option, see below.
65V	4H - 1/4" 6H - 3/8" 9H - 9/16"	07 - VEE stem 08 - regulating stem (tapered tip for regulating and shutoff) 87 - VEE stem with replaceable seat 88 - regulating stem with replaceable seat	1 - two-way straight 2 - two-way angle 3 - three-way, two on pressure 4 - three-way, one on pressure 5 - three-way, two-stem manifold	Extreme temperature option, see below.

Special Designs for Extreme Temperatures

Standard valves are supplied with Teflon/Carbon packing and may be operated to 450°F. High temperature packing and/or extended stuffing box are available for service from -423°F to 1200°F by adding the following suffixes to catalog order number.

- TG	standard valve with teflon glass packing to 600°F.
- GY	standard valve with graphite braided yarn packing to 800°F.
- HT	extended stuffing box valve with graphite braided yarn packing to 1200°F.
- B	standard valve with cryogenic trim materials and Teflon packing to -100°F.
- LT	extended stuffing box valve with teflon packing and cryogenic trim materials to -423°F.

Repair Kits

Consult your High Pressure Technologies representative for repair kits and valve bodies. Refer to the Tools and Installation section for proper maintenance procedures.

O.D. Size (in.)	Connection Type	Orifice Size (in.)	Rated Cv*	Pressure/Temp. Rating (psi @ R.T.)**

1/4	4HF	0.062	0.08	65,000
3/8	6HF	0.062	0.09	65,000
9/16	9HF	0.078	0.14	65,000

* Cv values shown are for 2-way straight pattern vee stem valves.
For 2-way angle patterns, increase the Cv value by 50%.
** See page 2 in the Technical Section for Pressure/Temperature Rating Chart.
