3-Way - 2 stem Manifold Valve

3-Way – 2-Stem Manifold

Catalog
Number

Stem
Type

O.D.
Tube
(in.)

Orifice
(in.)

Dimensions (in.)

Valve
Panel
Hole

Block
Thick-
ness

21V4M075

Vee

1/4

0.125

8.54

3.39

1.69

0.22

0.37

1.24

2.95

1.00

2.01

1.19

0.75

0.79

21V4M085

Reg

21V6M075

Vee

3/8

0.219

8.54

3.39

1.69

0.22

0.37

1.24

2.95

1.00

2.01

1.19

0.75

0.79

21V6M085

Reg

21V9M075

Vee

9/16

0.312

12.06

5.12

2.56

0.22

0.37

1.38

3.94

1.25

2.50

1.75

1.00

1.02

21V9M085

Reg

21V12M075

Vee

3/4

0.438

13.07

6.50

3.25

0.43

0.63

1.76

10.31

1.50

3.00

2.25

1.25

1.38

21V12M085

Reg

21V16M075

Vee

0.562

16.18

7.52

3.76

0.53

1.13

2.50

10.31

2.07

4.13

2.81

1.62

1.77

21V16M085

Reg

All dimensions are for reference only and are subject to change.
